Spec Miata Parts
MAZDASPEED MOTORSPORTS DEVELOPMENT carries the following Spec Miata parts to help you build your car.
The suspension kit includes an AWR Coil-Over kit with revised bump stops, Eibach 700lb front and 325 lb rear ERS race springs, and Eibach front and rear sway bar kit.
| Description | Part Number | |
| 1.6 Liter Miata | 000-02-5500 | |
| 1.6 Suspension Kit | K-SPEC-M5-SUSP | |
| Comp Limited Slip* | ||
| Spec Miata Exhaust Muffler (add converter pipe)(90-97) | 0000-06-5425 | |
| Converter replacement pipe 1.6 | 0000-06-5423 | |
| Converter replacement pipe 1.8 (94-97) | 0000-06-5424 | |
| *Axle stubs, p/n T005-27-270B, are needed for cars that came with a factory viscous-type limited slip. Vehicles with open diffs don’t need these. | ||
1.8 Liter Miata (94-97)
| 1.8 Suspension Kit (1st Gen Miata) | K-SPEC-M5-SUS8 | |
| Throttle Restrictor (94-95) | CONTACT SCCA ENTERPRISES | 303-693-2111 |
| Throttle Restrictor (96-97) | CONTACT SCCA ENTERPRISES | 303-693-2111 |
| Torsen Limited Slip (1.8 only) | MM03-27-200 |
1.8 Liter Miata (99-05)
| 1.8 Suspension Kit (Second Gen Miata) | K-SPEC-M5-SUS9 | |
| Throttle Restrictor | CONTACT SCCA ENTERPRISES | 303-693-2111 |
| Torsen Limited Slip | MM03-27-200 |
Optional Parts
| Green™ Air Filter (drop in) 1.6 or 1.8 |
0000-06-5201-GN
|
|
| Green™ Air Filter (drop in) (99-05) | 0000-06-5202-GN | |
| Stainless Steel Braided Brake Lines (90-05) | 0000-03-5211 | |
|
Subframe Bracing – 90-93 only (94-05 is already installed)
|
NA75-56-3AY | |
|
Subframe Bracing Tabs (helpful to install bracing, or make your own)
|
0000-04-5999 | |
|
R-package chin spoiler (90-97)
|
0000-86-510A
|
|
| Sport Package chin spoiler 99-05 | NC10-V4-900F primered NC10-V4-900F-XX (where XX is the color code, for painted spoilers. Replace XX with PZ for Black, SU for Classic Red, 46 for Emerald, 56 for Evolution Orange, 92 for Highlight Silver, 57 for Twilight Blue, PT for White |
|
| Tie Down/Tow Hooks | 0000-04-5998 (Includes one front and one rear tow hook with 2″ diameter hole) | |
| Adjustable sway bar end link – (order 4, 90-97 only) | 0000-04-5499 | |
| Competition Aluminum Radiator 90-97 |
0000-01-5501
|
|
| Competition Aluminum Radiator 99-05 | 0000-01-5503 | |
| Hard Top | NCY1-R1-81XB-98 | |
| Hard Top Bracket Kit | 0000-04-5997 | |
| Evaporator Replacement Tube | NA01-61-150A | Used when removing the evaporator to connect heater box to blower. |
| Evaporator Hole Plugs | 0187-53-134 , 1708-61-031 , & B499-62-868 | Two fill holes in firewall and one fills the drain hole in the transmission tunnel. |
