1990-2007 Miata / MX-5 Cooling System Parts
To order any of these parts, go back to the main motorsports webpage and login. Click on the Order More Item icon under the QUICK ORDER section on the top right of the Motorsports webpage (while logged in). You will see several blank lines at a time, to type in your part numbers. Click the SUBMIT button at the bottom of the page. This will add the items and return to your cart. You can repeat the process if you have more items to add.
These are all of the water hoses on the engine, plus other cooling system parts. There are no competition versions of any of these parts, except for the radiators.
| 1.6 Liter Hose kit can be ordered under 0000-01-HOSE-16 (items denoted with *) |
DESCRIPTION
|
PART NUMBER
|
QTY
|
NOTES
|
| 1.6 liter |
|
|
|
| Hose, Upper Radiator* |
B61P-15-186 |
1 |
|
| Hose, Lower Radiator* |
B61P-15-185 |
1 |
|
| Hose, Lower radiator* |
B61P-15-184 |
1 |
connecting pipe to water pump |
| Bypass Hose* |
B61P-13-681B |
1 |
Intake manifold to throttle body |
| Bypass Hose* |
B61P-13-682A |
1 |
Throttle body to air valve |
| Bypass Hose* |
B61P-13-691A |
1 |
Other side of air valve |
| Bypass Hose* |
B61P-15-261A |
1 |
At thermostat housing |
| Heater Hose* |
NA75-61-211 |
1 |
Right side, through firewall |
| Heater Hose* |
N007-61-212 |
1 |
Left side, through firewall |
| |
|
|
|
| Thermostat |
8AK1-15-171 -9U |
1 |
Does NOT Include gasket |
| Thermostat Gasket |
B621-15-173 |
1 |
|
| |
|
|
|
| Water Pump |
B660-15-010R-ME |
1 |
REBUILT – Includes gaskets |
| Gasket |
B366-15-165 |
1 |
Water pump to lower pipe |
| O-ring |
E301-15-287 |
1 |
O-ring around heater pipe |
| Gasket |
B6BF-15-116 |
1 |
Water pump to block |
| |
|
|
|
| Radiators |
|
|
|
| 1990-97 -MT |
BPE8-15-200 |
1 |
|
| 1990-93 – AT |
B64J-15-200C |
1 |
|
| Competition All Aluminum – MT |
0000-01-5501 |
1 |
|
|
1.8 Liter (94-97)
|
|
|
|
| 1.8 Liter Hose kit can be ordered under 0000-01-HOSE-18 (items denoted with *) |
| Hose, Upper Radiator* |
BPE8-15-186 |
1 |
|
| Hose, Lower Radiator* |
B61P-15-185 |
1 |
Same as 1.6 |
| Hose, Lower radiator* |
B61P-15-184 |
1 |
Same as 1.6 |
| Bypass Hose* |
BPE8-13-681 |
1 |
Throttle body to oil cooler |
| Bypass Hose |
BPE8-15-536 |
1 |
Oil Cooler to block |
| Bypass Hose* |
BPE8-13-682 |
1 |
Throttle body to thermostat housing |
| Bypass Hose* |
B61P-15-261A |
1 |
At thermostat housing |
| Heater Hose* |
NA75-61-211 |
1 |
Right side, through firewall – same as 1.6 |
| Heater Hose* |
NA75-61-212 |
1 |
Left side, through firewall. |
| |
|
|
|
| Thermostat |
8AB8-15-171 -9U |
1 |
Does not include gasket. |
| Thermostat Gasket |
B621-15-173 |
|
|
| |
|
|
|
| Water Pump |
B6BF-15-010F |
1 |
Does not include gaskets – All are needed |
| Gasket |
B6BF-15-116 |
1 |
Water pump to lower pipe |
| O-ring |
E301-15-287 |
1 |
O-ring around heater pipe |
| Gasket |
B366-15-165 |
1 |
Water pump to block |
| |
|
|
|
| Radiators |
|
|
|
| 1990-97 -MT |
BPE8-15-200 |
1 |
|
| 1994-97 – AT |
BPE9-15-200 |
1 |
|
| Competition All Aluminum – MT |
0000-01-5501 |
1 |
|
| |
|
|
|
| |
|
|
|
1.8 Liter (99-00)
|
|
|
|
| 1999-2000 1.8 Liter Hose kit can be ordered under 0000-01-HOSE-99 (items denoted with *) |
| Hose, Upper Radiator* |
BP4W-15-186B |
1 |
|
| Hose, Lower Radiator* |
BP4W-15-185 |
1 |
|
| Hose, Lower radiator* |
B61P-15-184 |
1 |
|
| Bypass Hose* |
BP4W-13-681B |
1 |
Throttle body to oil cooler |
| Bypass Hose* |
BP4W-13-682 |
1 |
Throttle body to thermostat housing |
| Bypass Hose* |
B61P-15-261A |
1 |
At thermostat housing |
| Heater Hose* |
NC10-61-211 |
1 |
Right side, through firewall – same as 1.6 |
| Heater Hose* |
NC10-61-212 |
1 |
Left side, through firewall. |
| |
|
|
|
| Thermostat |
BP6F-15-171A |
1 |
Does not include gasket. |
| Thermostat Gasket |
B621-15-173 |
1 |
|
| |
|
|
|
| Water Pump |
B6BF-15-010F |
1 |
Does not include gaskets – All are needed |
| Gasket |
B6BF-15-116 |
1 |
Water pump to lower pipe |
| O-ring |
E301-15-287 |
1 |
O-ring around heater pipe |
| Gasket |
B366-15-165 |
1 |
Water pump to block |
| |
|
|
|
| Radiators |
|
|
|
| 1999-2005 – MT |
BP4W-15-200A |
1 |
|
| 2004-2005 – MT TURBO |
BP8J-15-200A |
1 |
MAZDASPEED MIATA |
| 1999-2000 – AT |
BP4X-15-200A |
1 |
|
| 2001-2005 – AT |
BP6H-15-200 |
1 |
|
| 1999-2005 |
0000-01-5503 |
1 |
Competition All Aluminum – MT |
| |
|
|
|
| |
|
|
|
2.0 2006-2007
|
|
|
|
| |
|
|
|
| See online Catalog for hoses and other parts not shown. |
|
|
| Water Pump |
LF94-15-100A |
1 |
Includes o-ring seal. |
| |
|
|
|
| |
|
|
|
| Radiators |
|
|
|
| 2006-07 – MT |
LFG2-15-200E |
1 |
|
| 2006-07 – AT |
LFG1-15-200E |
1 |
|
| 2006 |
0000-01-5550 |
|
Competition All Aluminum – MT |
